USB Type-C connector
Product image is temporarily unavailableProduct appearance · configuration depends on the selected modelEnlarge image
I/O & data connectors
USB Type-C connector · Contact count: 5 · Current rating 1A
Series specification range: Positions / contacts: 5 · Voltage Withstanding: 100V AC/1Minute
Quotation and selection support
- Positions / contacts
- 5
- Voltage Withstanding
- 100V AC/1Minute
- Current rating
- 1A AC/DC
- Contact resistance
- 50m Ohms Max.
Parameters may cover a series or several configurations. Confirm ratings for the selected contact count, dimensions and termination.
Product overview
USB Type-C connector. USB Type-C connector. Series configuration parameters: Positions / contacts: 5; Voltage Withstanding: 100V AC/1Minute; Current rating: 1A AC/DC.
Discuss this product requirementProduct features
Voltage Withstanding
100V AC/1Minute
Current rating
1A AC/DC
Contact resistance
50m Ohms Max.
Durability
10000 Cycles
Product images
Technical specifications
Parameters may cover a series or several configurations. Confirm ratings for the selected contact count, dimensions and termination.
Mechanical & connection
| Durability | 10000 Cycles |
|---|---|
| Gender | Female |
| Positions / contacts | 5 |
Electrical & signal
| Voltage Withstanding | 100V AC/1Minute |
|---|---|
| Current rating | 1A AC/DC |
| Contact resistance | 50m Ohms Max. |
| Insulation resistance | 100M Ohms Min./500 VDC |
| Current rating | 1A |
| Voltage Withstanding | 100V AC/1Min |
Environmental conditions
| Operation temperature | -30℃ ~ +80℃ |
|---|---|
| Storage temperature | -30℃ ~ +80℃ |
| SMT Peak Temperature | 245 ± 5℃ 10S |
Drawings & technical files
USB Type-C connector drawing request
After selecting the connection configuration, review its dimensions, pin assignment and installation requirements. Include the required configuration in your request.
Request this product drawingSelection questions
How many positions or contacts are specified?
Positions / contacts: 5. Where a range or multiple options are shown, select the required count and pin assignment.
What voltage values and standards apply?
Voltage Withstanding: 100V AC/1Minute; Voltage Withstanding: 100V AC/1Min. Keep each value with its stated standard, class and test condition.
What current values and conditions apply?
Current rating: 1A AC/DC; Current rating: 1A. Keep each value with its stated standard, class and test condition.
What is specified for Contact resistance?
Contact resistance: 50m Ohms Max..
