Pitch
3.0 mm
Wire-to-board connector
Product image is temporarily unavailableProduct appearance · configuration depends on the selected modelEnlarge image
Wire connectors
Wire-to-board connector · 3.0 mm · Vertical · Insulation resistance ≥1000MΩ
Series specification range: Pitch: 3.0 mm · Mounting orientation: Vertical
Quotation and selection support
- Pitch
- 3.0 mm
- Mounting orientation
- Vertical
- Termination style
- Solder
- Rated current
- Max 8.5A per pin
Parameters may cover a series or several configurations. Confirm ratings for the selected contact count, dimensions and termination.
Product overview
Wire-to-board connector. Wire-to-board connector. Series configuration parameters: Pitch: 3.0 mm; Mounting orientation: Vertical; Termination style: Solder.
Discuss this product requirementProduct features
Mounting orientation
Vertical
Termination style
Solder
Rated current
Max 8.5A per pin
Connection type
Snap-On
Product images
Technical specifications
Parameters may cover a series or several configurations. Confirm ratings for the selected contact count, dimensions and termination.
Mechanical & connection
| Durability | High |
|---|---|
| Termination style | Solder |
| Mating Cycles | ≥30 cycles |
| Pitch | 3.0 mm |
| Mounting orientation | Vertical |
Electrical & signal
| Rated current | Max 8.5A per pin |
|---|---|
| Rated voltage | 600V AC/DC |
| Contact resistance | < 20 mΩ max after mating cycles |
| Insulation resistance | ≥1000MΩ |
| Withstand voltage | AC 1500V, 1min no breakdown |
Materials & finish
| Plating | tin plating |
|---|---|
| Housing | PA66, UL94V-0 Black |
| Contact material | Brass Alloy |
| Plating | tin plating / gold plating optional |
Environmental conditions
| Temperature range | -40 To 85 °C |
|---|
Other specifications
| Connection type | Snap-On |
|---|---|
| Contact | Brass With gold plating Over 50U |
| Vibration / Shock | Compliant with EIA-364, no discontinuity |
| Reflow soldering | Peak temp 260℃, compatible with SMT reflow |
Drawings & technical files
Wire-to-board connector drawing request
After selecting the connection configuration, review its dimensions, pin assignment and installation requirements. Include the required configuration in your request.
Request this product drawingSelection questions
What is the connection pitch?
Pitch: 3.0 mm. The PCB footprint or mating interface must use the pitch of the selected configuration.
What mounting arrangement is used?
Mounting orientation: Vertical. Check installation clearance and mating geometry for this configuration.
What termination arrangement is used?
Termination style: Solder. Check installation clearance and mating geometry for this configuration.
What current values and conditions apply?
Rated current: Max 8.5A per pin. Keep each value with its stated standard, class and test condition.
