Pitch
1.25 mm
Wire-to-board connector
Product image is temporarily unavailableProduct appearance · configuration depends on the selected modelEnlarge image
Wire connectors
Wire-to-board connector · 1.25 mm · Contact count: 2-16 PIN · Gender Female
Series specification range: Pitch: 1.25 mm · Pin number: 2-16 PIN
Quotation and selection support
- Pitch
- 1.25 mm
- Pin number
- 2-16 PIN
- Gender
- Female
- Contact resistance
- 40MΩ Max
Parameters may cover a series or several configurations. Confirm ratings for the selected contact count, dimensions and termination.
Product overview
Wire-to-board connector. Wire-to-board connector. Series configuration parameters: Pitch: 1.25 mm; Pin number: 2-16 PIN; Gender: Female.
Discuss this product requirementProduct features
Pin number
2-16 PIN
Gender
Female
Contact resistance
40MΩ Max
Rated voltage
125V AC DC
Product images
Technical specifications
Parameters may cover a series or several configurations. Confirm ratings for the selected contact count, dimensions and termination.
Mechanical & connection
| Gender | Female |
|---|---|
| Pin number | 2-16 PIN |
| Pitch | 1.25 mm |
Electrical & signal
| Contact resistance | 40MΩ Max |
|---|---|
| Rated voltage | 125V AC DC |
| Withstand voltage | 500V AC/MINUTE |
Environmental conditions
| Storage temperature | -25°C~+85°C |
|---|
Other specifications
| Type | Connector |
|---|
Drawings & technical files
Wire-to-board connector drawing request
After selecting the connection configuration, review its dimensions, pin assignment and installation requirements. Include the required configuration in your request.
Request this product drawingSelection questions
What is the connection pitch?
Pitch: 1.25 mm. The PCB footprint or mating interface must use the pitch of the selected configuration.
How many positions or contacts are specified?
Pin number: 2-16 PIN. Where a range or multiple options are shown, select the required count and pin assignment.
What is specified for Gender?
Gender: Female.
What is specified for Contact resistance?
Contact resistance: 40MΩ Max.
Confirm the configuration. Get a quote.
Share the model or required specification, quantity and delivery target.
